Designing a dream kitchen doesn’t have to include compromises. With Cattura, the downdraft system from BEST, you can design confidently, knowing it will pair with a broad range of cooktop appliances - aesthetically and mechanically - in virtually any installation configuration.
VERTEX™Complete capture design technology performs as well as an island hood.
LED LIGHT BAR
Evenly illuminates the entire cooking surface.
TOUCH OF A BUTTON 18"
A touch of a button raises or lowers the 18" downdraft.
EASY TO CLEAN CONTROL PANEL
Sleek, easy-to-clean touch-control panel.
OPTIONAL REMOTE CONTROL
An optional remote control button raises or lowers the downdraft as needed.
Features
- Speeds:
4 - Ducting Information:
Rectangular or Round - Additional Information:
• At the touch of a button the Cattura downdraft quickly rises to a height of 18" to handle serious cooking ventilation requirements and tall pots - even on the front burners
• VERTEX™ Complete Capture Design technology
• Up to 35% quieter operation than any other downdraft
• Long-lasting two-level LED task lighting provides impressive cooktop illumination, even on the front burners
• Easy to clean four-speed glass touch controls with a convenient 10-minute time-delay shut-off feature and filter maintenance reminder light
• Heat Sentry™
• Optional remote control raises or lowers downdraft from another location
• Works with optional Automatic Make-Up Air Dampers
• Non-ducted capability
• Mesh grease filter
Accessories
- Optional:
• Internal Blower : PF6 FlexBlower (CFM 600) Sones 8.8
• External In-Line : ILB3 (CFM 280), ILB6 (CFM 600), ILB9 (CFM 800), ILB11 (CFM 1100)
• External Exterior : EB6 (CFM 600), EB9 (CFM 900), EB12 (CFM 1200), EB15 (CFM 1500)
Documents
- Product Sheet (en)
- Dimensions Guide (en)
- Owner's manual (en)
- Installation guide (en)
- Additional documents(en)
Videos
- BEST CATTURA DOWNDRAFT INSTALLATION OPTIONS
- SHADOWGRAPH IMAGING PROVES BEST CATTURA DOWNDRAFT HAS SUPERIOR CAPTURE ABILITY
*While we place great care into preparing product descriptions and prices, sometimes technical and typographical errors or omissions may occur. Appliance Canada cannot be held responsible for such errors and we apologize for any inconvenience this may cause.
Specifications
Series Name
CatturaManufacturer Color
Black Stainless SteelColor
Black StainlessInstallation
Built-InBlower Included
NSpeeds
4Ducting Information
Rectangular or RoundAdditional Information
• At the touch of a button the Cattura downdraft quickly rises to a height of 18" to handle serious cooking ventilation requirements and tall pots - even on the front burners
• VERTEX™ Complete Capture Design technology
• Up to 35% quieter operation than any other downdraft
• Long-lasting two-level LED task lighting provides impressive cooktop illumination, even on the front burners
• Easy to clean four-speed glass touch controls with a convenient 10-minute time-delay shut-off feature and filter maintenance reminder light
• Heat Sentry™
• Optional remote control raises or lowers downdraft from another location
• Works with optional Automatic Make-Up Air Dampers
• Non-ducted capability
• Mesh grease filterOptional
• Internal Blower : PF6 FlexBlower (CFM 600) Sones 8.8
• External In-Line : ILB3 (CFM 280), ILB6 (CFM 600), ILB9 (CFM 800), ILB11 (CFM 1100)
• External Exterior : EB6 (CFM 600), EB9 (CFM 900), EB12 (CFM 1200), EB15 (CFM 1500)Information
120 VHeight
45.72 cmDepth
5.72 cmWidth
76.2 cmClass Width
30"Additional Dimensions
For more information please refer to dimension guideWarranty
Limited 1-Year Parts and LaborUPC#
26715255702
